Powder Granulator, Fertilizer Pellet Machine With Flat Ball Shape
The feature of the roller extrusion granulator
This machine adopts no drying process production, normal
temperature granulation, molding. With less investment, quick
effect, good economic benefits and other characteristics. This
machine adopts granulation, molding and screening as a whole, which
has the advantages of beautiful appearance, simple operation, low
energy consumption. The The main parts, such as the roller body
with anti-corrosion, wear-resistant, anti shock characteristics of
a new type of metal refining.
The instruction of the roller extrusion granulator
1. No drying technology, normal temperature granulating, once
forming.
2. Low investment, quick profit, good economic returns, etc.
3.Combine granulating,forming,screening into one machine,making
beautiful appearance
granules, easy operation and low energy consumption, etc.
4. Especially, DZJ-5. not only has the above features, but also
upgrades its rack.The bearing
frame body is made of high quality and anticorrosive cast
materials, so that it become more
stable and extends the roller's service life.
The advantage of the roller extrusion granulator
1.Low investment, quick profit, good economic returns, etc.
2.No drying technology, normal temperature granulating, once
forming
3.Combine granulating, forming, screening into one machine, making
beautiful appearance granules, easy operation and low energy
consumption, etc.
4.The main components, such as the roller body, is made of a new
type of metal which is anticorrosive,wearable and impact
resistance.
5.Especially, DZJ-II not only has the above features, but also
upgrades its rack. The bearing frame body is made of high quality
and anticorrosive cast materials, so that it become more stable and
extends the roller's service life.
Specifications of the roller extrusion granulator
Model | DZJ~I 1.0 | DZJ~I 2.0 | DZJ~I 3.0 | DZJ~I 4.0 | DZJ~II 1.0 | DZJ~II 2.0 |
Product capacity(t/h) | 1~1.5 | 1.5~2.5 | 2.5~3.5 | 3.5~4.5 | 1~2 | 1.5~2.5 |
Power | 15KW | 18.5KW | 30KW | 45KW | 15KW | 18.5KW |
Pressure roller Spececification | Φ150×22O | Φ150×30O | Φ186×30O | Φ300×30O | Φ150×22O | Φ150×30O |
Feed size | ≤0.5mm | ≤0.5m | ≤ 0.5mm | ≤ 0.5mm | ≤0.5mm | ≤0.5mm |
Finished product Spec | Φ2.5~Φ10 | Φ2.5~Φ10 | Φ2.5~Φ20 | Φ2.5~Φ30 | Φ2.5~Φ10 | Φ2.5~Φ20 |
Speed reducer Model | ZQH350 | ZQH400 | ZQH400 | ZQH500 | dedicated | dedicated |
Material moisture content | 2%~5% | 2%~5% | 2%~5% | 2%~5% | 2%~5% | 2%~5% |
