Compound Fertilizer Making Equipment And Rotary Drum Granulator
Factory
Fertilizer Granules Making Machine Oveview:
(1) NPK Compound Fertilizer Granules Machine is one of the key
equipment in compound fertilizer industry.
(2) It is suitable for hot and cold granulation and high, medium
and low concentrations of mass production of compound fertilizer.
(3) The shell of the machine uses special rubber slab lining or
acid-resistant stainless lining board which realizes auto scar
removal and de-tumor instead of traditional drawknife equipment
(4) High balling strength, good appearance, corrosion resistance,
wear resistance, low energy consumption, long service life, easy
operation and maintenance, etc
Characteristics of Performance:
1. Innovate technology, and improved structure; the tube uses
special rubber sheet lining or acid resistant stainless steel
liner, realizing automatic removal of scar, deoma.
2. High wear resistance, convenient maintenance, high ball
strength, good appearance, corrosion resistance, wear resistance,
low energy consumption, long service life, convenient operation and
maintenance.
3. Reasonable layout, advanced technology, small power, no three
wastes discharge, stable operation, convenient maintenance.
4. High balling rate; the drying efficiency is high; the balling
rate can reach 70%; there is a small amount of returning material,
the size of returning material is small and can be Re granulated.
Steam heating to raise the material temperature.
Raw material classification | Specific application |
Inorganic fertilizer | BB and compound fertilizer powder |
Biologics | Western medicine granules etc |
Coal industry | Carbon granule etc |
Others | Kinds of inorganic powder that you need manufacture granules |
Technical Parameters for Rotary Drum Granulator
Model | Barrel | Power | Prod Capacity | Overall dimensions L× W ×H | weight |
Inclination | Internal diameter | length | Rotation speed |
0 | m | m | r/min | kw | t/h | m | t |
ZG1.2×4 | 2-2.5 | 1.2 | 4 | 17 | 5.5 | 1-3 | 4.6×2.2×2.0 | 2.7 |
ZG1.4×5 | 2-2.5 | 1.4 | 5 | 14 | 7.5 | 3-5 | 4.8×2.8×2.3 | 8.5 |
ZG1.6×6 | 2-2.5 | 1.6 | 6 | 11.5 | 11 | 5-8 | 7.0×3.2×3.1 | 12.0 |
ZG1.8×7 | 2-2.5 | 1.8 | 7 | 11.5 | 15 | 8-10 | 8.3×3.5×3.3 | 18.5 |
ZG2.0×8 | 2-2.5 | 2.0 | 8 | 11 | 18.5 | 10-15 | 9.1×3.6×3.5 | 22.0 |
ZG2.2×8 | 2-2.5 | 2.2 | 8 | 10.5 | 22 | 15-20 | 9.5×4.4×3.9 | 28.0 |
Features and Advantages
1. Main products: compound and organic fertilizer granulator,
mixer, belt conveyor, dryer, screening machine, dewatering machine,
crusher, weighing packaging machine, etc.
2. Designated production enterprise by Agriculture Department
3. We account for 80% market shares in compound and bio-organic
fertilizer manufacturing filed in China.
4. Processional Research and Development team
5. Strict quality control system
6. We provide competitive prices, reliable quality products and
swift delivery time.
7. Exported to more than 30 countries in Africa, South America, Mid
East, Central America and other area, such as, India, Korea,
Australia, etc.
